Page 37
For technical questions, please call 1-888-866-5797.
70476
SAFETYOPERATIONMAINTENANCE SETUP
Part Description Qty
1 Hex Socket Flange Face Bolt - Small Series 4
2 Cylinder Head Cover Subassembly 1
3 Cylinder Head Cover Gasket 1
4 Stop Detent 1
5 Breather Tube 1
6 Pipe Clamp 2
7 Inner Cylinder Head Cover 1
8 Gasket 1
9 Valve Rocker Subassembly 2
10 Rocker Shaft Subassembly 2
11 Hex Socket Flange Face Bolt - Small Series 3
12 Cylinder Head Cover Pin Limit Plate 1
13 Valve Rotator 2
14 Valve Lock Clamp 4
15 Valve Spring Seat 2
16 Valve Spring 2
17 Seal Guide 1
18 Cylinder Head Bolt 4
19 Cylinder Head Subassembly 1
20 Exhaust Pipe 1
21 Type 1 Nut 2
22 Muffler Gasket 1
23 Stud Bolt 2
24 Spark Plug 1
25 Cylinder Head Gasket 1
26 Position Pin - Type A 2
27 Valve Set 1
28 Valve Lifter Subassembly 2
29 Valve Tappet 2
30 Piston Ring Assembly 1
31 Piston 1
32 Connecting Rod 1
33 Piston Pin 1
34 Piston Pin Clip 2
35 Temperature Sensor 1
36 Hex Socket Flange Face Bolt - Small Series 1
37 Cylinder Body Shroud 1
38 Flat Washer 2
39 Hex Socket Flange Face Bolt - Small Series 2
40 Crankcase Air Deflector 1
41 Oil Seal 1
42 Hex Socket Flange Face Bolt - Small Series 2
43 Starting Motor Assembly 1
44 Drain Plug Bolt 2
45 Wire Clip 3
46 Rubber Plug 1
47 Crankcase Subassembly 1
48 Deep Groove Ball Bearing - P6 1
49 Crankshaft Assembly 1
50 Balancing Shaft 1
51 Camshaft Assembly 1
52 Engine Oil Sensor 1
53 Hex Socket Flange Face Bolt - Small Series 2
54 Flange Nut 1
55 Position Pin - Type A 2
56 Crankcase Gasket 1
57 Deep Groove Ball Bearing - P6 1
Part Description Qty
58 Deep Groove Ball Bearing - P53 1
59 Oil Dipstick Subassembly 1
60 Crankcase Cover 1
61 Hex Socket Flange Face Bolt - Small Series 9
62 Oil Seal 1
63 Pipe Clamp 2
64 Shroud 1
65 Hex Socket Flange Face Bolt - Small Series 5
66 Recoil Starter Assembly 1
67 Ignition Coil 1
68 Hex Socket Flange Face Bolt - Small Series 2
69 Flywheel Nut 1
70 Starter Pulley 1
71 Impeller 1
72 Hex Socket Flange Face Bolt - Small Series 1
73 Charge Coil Clamp 1
74 Flywheel Subassembly 1
75 Hex Socket Flange Face Bolt - Small Series 4
76 Charge Coil Subassembly 1
77 Throttle Bottom Plate 1
78 Hex Socket Flange Face Bolt - Small Series 3
79 Stud Bolt 2
80 Inlet Gasket 1
81 Carburetor Insulator Plate 1
82 Carburetor Seal Gasket 1
83 Carburetor Assembly 1
84 Air Cleaner Seal Gasket 1
85 Pipe Clamp 1
86 Rubber Jacket 1
87 Fuel Tube 1
88 Rubber Jacket 1
89 Hex Socket Flange Face Bolt - Small Series 1
90 Air Cleaner Bracket 1
91 Air Cleaner Assembly 1
92 Flange Nut 2
93 Air Cleaner Element 1
94 Air Duct 1
95 Small Spiral Narrow Band Collar - Type A 1
96 Muffler Gasket 1
97 Hex Socket Flange Face Bolt - Small Series 2
98 Muffler Assembly 1
99 Hex Socket Flange Face Bolt - Small Series 2
100 Muffler Bracket 1
101 Hex Socket Flange Face Bolt - Small Series 2
102 Motor Shroud 1
103 Hex Socket Flange Face Bolt - Small Series 1
104 Stator Nut 2
105 Flat Washer 2
106 Standard Spring Washer 2
107 Motor Assembly 1
108 Carbon Brush Subassembly 1
109 Hex Socket Flange Face Bolt - Small Series 1
110 Terminal Block 1
111 Hex Socket Flange Face Bolt - Small Series 2
112 Stopper 1
113 Motor Support 1
114 Hex Socket Flange Face Bolt - Small Series 1
Parts List and Diagram
Parts List
