Page 6
For Generator technical questions, please call 1-800-444-3353.
For Engine technical questions, please call 1-800-520-0882.
Item 69672 / 69674
SAFETY OPERATION MAINTENANCESETUP
Functional Description
Specications
Generator
Rated Output
120/240V~, 60Hz
5,500 Watts (6,500 max)
Electrical Receptacle
Two 3-Prong, duplex NEMA #5-20 120V
One 4-Prong, NEMA #L14-30 twistlock 120V/240V
One DC Outlet 12VDC
Engine
Displacement 420cc
Engine Type
Horizontal Single Cylinder 4 stroke OHV
EPA phase III compliant
Cooling System Forced air cooled
Fuel
Type 87+ octane unleaded gasoline
Capacity 6.1 Gallons (23L)
Engine Oil
Type SAE
10W-30 above 32° F
5W-30 at 32° F or below
Capacity 1.16 Quart (1.1L)
Run Time @ 50% load 12 hr.
Operational Volume 74 dB
Available accessories Wheel kit (sold separately)
Item 69674 - The emission control system for this Generator’s Engine is warranted for standards set by the U.S.
Environmental Protection Agency and by the California Air Resources Board (also known as CARB). For warranty
information, refer to the last pages of this manual.
Item 69672 - The emission control system for this Generator’s Engine is warranted for standards set by the U.S.
Environmental Protection Agency. For warranty information, refer to the last pages of this manual.
Components and Controls
Fuel Cap
Frame
Starter
Handle
DC Circuit Breaker
Fuel Valve
Power Switch
AC Circuit Breakers
Choke
Low Oil Indicator
AC Receptacles
Air Filter
DC Receptacle
Ground Terminal
To Next Page
