Disassembly Procedures 1-13
Figure 1-13. SSD Module Removal
6. Detach the SSD module from the adhesive graphite strip (marked with yellow dashed
line) as shown in Figure 1-14.
Figure 1-14. SSD Module Removal
7. Repeat steps 5~6 to remove the copper foil with mylar from another SSD module.
WEEE Annex VII Component:
SSD Modules
To Next Page
