Predator PH16-71 - DIMM Modules Removal

1-14 Disassembly Procedures
DIMM Modules Removal 0
Prerequisite:
Battery Pack Removal
1. Find the DIMM modules (A) in the system (Figure 1-15).
2. Push the DIMM module clips (B) outwards (Figure 1-15).
Figure 1-15. DIMM Module Removal
3. Disconnect the DIMM module from the mainboard connector (C) (Figure 1-16). Then
remove the DIMM module.
Figure 1-16. DIMM Module Removal
A
A
B
B
C
