Disassembly Procedures 1-15
4. Repeat steps 2~3 to remove another DIMM module.
5. Peel off the composite foil with thermal pad (D) from the DIMM module
(Figure 1-17).
Figure 1-17. DIMM Module Removal
6. Detach the DIMM module from the adhesive graphite strip (marked with yellow
dashed line) as shown in Figure 1-18.
Figure 1-18. DIMM Module Removal
7. Repeat steps 5~6 to remove the composite foil with thermal pad from another DIMM
module.
D
WEEE Annex VII Component:
DIMM Modules
