Panel Core
Thickness
Wall Panel Height (ft.)
8’ 10’ 12’ 16’ 20’ 24’
3 1/2”
3500 2553 2452 NA NA NA
5 1/2”
4250 4042 3373 3358 NA NA
7 1/4”
4917 4325 4473 4194 3496 NA
9 1/4”
4200 4200 4200 4200 3389 NA
11 1/4”
3890 3890 3890 3890 3890 NA
Axial loads represent ultimate load divided by a safety factor of 3.
Loads do not reflect secondary effect of P∆
More information on this chart can be found in Technical Bulletin #4
Axial Load Chart 1:
Allowable Axial Loads (plf) for
Premier Type S (Spline) SIPs
