Load Chart 11:
Premier SIPs
1
Maximum
Allowable Diaphragm Loads
Minimum
OSB Face
Thickness
Attachments
Shear
(plf)
Panel Supports Panel Joints - Top Only
Panel Joints -
Top & Bottom
Fasteners Spacing Fasteners Spacing Fasteners Spacing
7/16”
PBS
Screw
2
12 inches 8d nail 3 inches 8d nail 6 inches 425
7/16”
PBS
Screw
2
3 inches 8d nail 2 inches 8d nail 4 inches 510
7/16”
PBS
Screw
2
4 inches
8d nail - 2
rows
3 inches
8d nail - 2
rows
6 inches 917
23/32”
PBS
Screw
2
4 inches
8d nail - 2
rows
3 inches
8d nail - 2
rows
6 inches 1136
1. The maximum panel height-to-width ratio shall be 4.5:1. 2. Premier Building Systems specially-designed big screws.
