PRESONUS Central Station Plus - Page 53

35
Owner’s Manual
Technical Information
6
Input Meters 输入仪表
Type 类型 30-segment LED w/Peak Hold
Range 范围 -48 dB to +18 dB (-66 dBfs to 0 dBfs)
Accuracy 精准度 Better than 0.25 dB 超过
Frequency Range 频率范围 10 Hz-22kHz
CalibrateRange 校准范围 ±18 dB
Power Supply 电源
Type 类型 External 外部
Power InputVoltage Range 电源输入电压范围 12-18 VDC
Power Requirements (continuous) 功率要求 （连续） 10W
Physical
实体
Main Chassis 主机箱
PackageType 包装类型 1U
Dimensions 尺寸 19 (W) X 1.75 (H) X 5.50 (D) inches
Weight 重量 5.0 lbs.
Asacommitmentto constantimprovement,PreSonus Audio
Electronics, Inc., reserves the right to change any
specification stated herein, at any time, without notification.
作为对不断改进的承诺，这里所述的任何规格，PreSonus
Audio Electronics, Inc.公司 保留在任何时候修改的权利，不
做另行通知。
Getting Started
Overview
Calibration
Sample Hookup Diagrams
Controls
and Connections
Technical Information
