2 CONTROLS & CONNECTIONS
7
2.1 FRONT PANEL BASI C LAYOUT
The front panel of the EUREKA is divided into four sections – Preamplifier,
Compressor, Equalizer and Master.
Preamplifier section:
? Gain Control
? Impedance Control
? Saturation Control
? +48 Volt Switch
? -20db Pad
? Phase Reverse Button
? 80Hz Filter
? Line Input Select Button
? LED Input Meter
