Jazzy Elite Series www.pridemobility.com 7
III. YOUR POWER CHAIR
THE JAZZY ELITE SERIES POWER CHAIR
The Jazzy Elite Series Power Chair has two main assemblies: the seat assembly and the power base assembly. See
figure 1. Typically, the seat assembly includes the armrests, seatback, and seat base. The power base assembly
includes two motor/brake assemblies, two drive wheels, two rear caster wheels, two front anti-tip wheels, two
batteries, and wiring harnesses.
Figure 1. The Jazzy Elite Series Power Chair
SEAT
ASSEMBLY
FRONT RIGGING
(FOOT PLATFORM SHOWN)
DRIVE WHEEL
ANTI-TIP WHEELS
SEATBACK
ARMRESTS
MAIN SHROUD
CONTROLLER
SEAT BASE
POWER BASE
ASSEMBLY
CASTER WHEEL
