18 www.pridemobility.com US Jazzy 1113/Rev I/Feb03
IV. THE JAZZY 1113
Figure 2. Power Base Back View
FRONT BATTERY BOX
REAR BATTERY BOX
BATTERY CONNECTORS
SEAT POSTS
MOTOR CONNECTORS
Figure 3. Power Base Top View
CHARGER INHIBIT CONNECTOR
9-PIN CONTROLLER CONNECTOR
AMMETER
MAIN CIRCUIT BREAKER
BATTERY CHARGER AC POWER CORD RECEPTACLE
SEAT POSTS
