US Jazzy 1113/Rev I/Feb03 www.pridemobility.com 17
IV. THE JAZZY 1113
Specifications
Suspension: Limited suspension
Drive Wheels: 10 in., pneumatic (solid tires are optional)
Caster Wheels: 8 in., solid, rear articulating
Anti-Tip Wheels: 6 in., solid, front mounted
Maximum Speed: Up to 4 mph
Brakes: Intelligent Braking, electronic regenerative, disc park brake
Ground Clearance: 2 in.
Turning Radius: 16.5 in.
Overall Size: Length: 32 in.
Width: 23 in. (assembled)
Seating Options: Medium Back (standard)
High Back with headrest (standard)
Synergy Seat
Versa Tilt
Drivetrain: Two motor, mid-wheel
Batteries: Two 12-volt, U-1 batteries
Range: Up to 25 miles
Battery Charger: 3 amp, Onboard
3 amp, Off-board (optional)
Electronics: 50-amp P&G VSI Controller
70-amp Europa Remote Controller
70-amp P&G Remote Plus Controller
Weight Capacity: 300 lbs. (160 lbs. with Tilt)
Component Weights: Seat: 33 lbs.
Footrest: 8.5 lbs.
Front battery and case: 26 lbs. (U-1) (Battery 24.5 lbs.)
Rear battery and case: 26 lbs. (U-1) (Battery 24.5 lbs.)
Battery well frame: 13 lbs.
Front frame: 2.5 lbs.
Right frame assembly: 33 lbs.
Left frame assembly: 33 lbs.
Warranty: Lifetime limited warranty on frame
2-year limited electronics warranty
18 months on drive motors
