IV. YOUR POWER CHAIR
THE JAZZY 600
The Jazzy 600 has two main assemblies: the seat assembly and the power base assembly. See figure 5. Typically, the seat
assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake assemblies,
two drive wheels, four caster wheels, two batteries, and wiring harnesses. See figure 5, 6, and 7.
SEATBACK
REAR
SHROUD
DRIVE WHEEL
CASTER WHEEL
Figure 5. The Jazzy 600
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOT RIGGING
(FOOT PLATFORM SHOWN)
SEAT BASE
SEATBACK
RELEASE LEVER
ARMRESTS
CONTROLLER
( FLIGHT SHOWN)
CASTER WHEEL
MANUAL FREEWHEEL LEVER
