14 www.pridemobility.com Quantum/Jazzy 1450 Series
IV. ASSEMBLY
Figure 10. Controller Harness Routing on a Contour
Seat
Figure 9. Controller Harness Routing on a Synergy
Seat
Figure 8. Quantum/Jazzy 1450 Series Power Chair with
Synergy Seating System
TO POWER BASE
WIRE TIES
