Olympian Autolift www.pridemobility.com 15

V I . I N S T A L L I N G A N D R E M O V I N G

INSTALLING

1. Rest the upper mounting lug onto the longer upper pin before aligning the lower pin. The hoist

should slide smoothly down into place.

2. Half engage actuator pin

3. Rotate the hoist and align with it actuator

4. Fasten together with the actuator pin – Ensure the pin is fully engaged

5. Fully insert the Retaining Clip into the top pin

6. Clip the power connectors securely together
