36
www.pridemobility.com Ultimate-4 XL
X. CARE AND MAINTENANCE
LIGHT BULB REPLACEMENT
The scooters light bulbs are easily replaceable. Do not use regular automotive-type 12-volt light bulbs; your
scooter is equipped with a 24-volt electrical system. Replacement light bulbs can be purchased from your authorised
Pride Provider.
NOTE: Use only 24-volt light bulbs.
1. Remove the light cover.
2. Gently remove the bulb by pulling it straight out.
3. Insert a new bulb of the same wattage.
4. Replace the light cover.
STORING YOUR SCOOTER
If you plan on not using your scooter for an extended period of time, it is best to:
n Fully charge its batteries prior to storage.
n Disconnect the batteries from the scooter.
n Store your scooter in a warm, dry environment.
n Avoid storing your scooter where it will be exposed to temperature extremes.
WARNING! Always protect batteries from freezing temperatures and never charge a frozen
battery. This damages the battery and can cause personal injury.
For prolonged storage, you may wish to place several boards under the frame of your scooter to raise it off of the
ground. This takes the weight off the tyres and reduces the possibility of flat spots developing on the areas of the
tyres contacting the ground.
CONSOLE, CHARGER, AND REAR ELECTRONICS
n Keep these areas free of moisture.
n Allow these areas to dry thoroughly if they have been exposed to moisture before operating your scooter again.
FUSE REPLACEMENT
In the event a fuse should cease to work:
n Remove the fuse by pulling it out of its slot.
n Examine the fuse to be sure it is blown. See figures 20 and 21.
n Insert a new fuse of the proper rating.
Figure 20. Working Fuse
WARNING! The new fuse must match the rating of the fuse being replaced. Failure to use
properly rated fuses may cause damage to the electrical system and may result in personal
injury.
Figure 21. Blown Fuse (Replace)
