4
Your ViValift! Power reCliner
4. Plug in the lumbar and headrest connectors. If
your model is Headrest Only, you only need to
plug in the Headrest.
5. If your model has back wings, align the KD
sleeves, and slide the wing down into place,
see figure 3. Please note there is a label on
the brackets. Please assemble them as indi-
cated (1-1 and 2-2).
6. Connect the Power Transformer cable to the
corresponding plug coming from the back of
the chair, (see figure 2).
7. Connect the Power Cord into the Power Trans-
former (see figure 2).
8. Connect the power cord into an electrical outlet
near where the chair will be used.
Figure 3. Wing Back Installation
