16 www.pridemobility.com Lift Chair Series
LIFT CHAIR SERIES
IV. ASSEMBLY/DISASSEMBLY
FABRIC REMOVAL/INSTALLATION
The fabric on some lift chairs can be removed to make cleaning and service of the chair more convenient. If
your chair is equipped with removable fabric, please see below.
Follow these steps to remove and install the lift chair fabric:
4.4.1 Disconnect the hand control from the quick
release cable located in the lift chair side
pocket. Place the hand control in a safe loca-
tion out of the way.
4.4.2 Push the quick release cable through the “V”
cut hole in the side pocket of the lift chair.
4.4.3 Slide the left and right side arm covers off of
the metal side arms.
4.4.4 For C6 Lift Chairs, unzip the chaise pad from
the chair-back cover.
