Dynamo
13
Model Numbers SC-180
Length 41in.
Width 21.5in.
Tires Type: Pneumatic; Front: 2in. x 8in. , Rear: 2.5in. x 9in.
Weight Capacity 250 lbs. maximum
Battery Type (Batteries not included) Two 12 volt, 32 AH, U-1 type, SLA (sealed lead acid)
Horsepower 1.0 hp (peak)
Charger Onboard 3-amp charger
Speed (max) Variable up to 4.75 mph (60% reverse)
Maximum Grade Please refer to figure 1
Range 20 - 25 miles per charge with 32 AH batteries
Turning Radius 31in.
Body Colors Painted: Gray
Seating Style: Low Back
Dimensions: 17in
. width (usable) x 12.5in. height (usable) x
14in
. depth
Seat Cover Material: Vinyl: Blue or Burgundy
Armrests: Match
User Adjustable seat height from ground: 21.25in. to 23.25in.
User Adjustable seat height from scooter deck: 15.5in. to 17.5in.
Included Features Adjustable seat height and positioning
Brakes Electronic regenerative braking and electromechanical disc brake
Rear Wheel Drive Sealed transaxle, 24 VDC motor differential
Wheels Pride Micro-Mag aluminum alloy wheels
Tiller Type Multi-position adjustable
Freewheel Mechanism Freewheel release lever located on transaxle
Scooter Weight TOTAL weight w/batteries: 146 lbs.
TOTAL weight w/o batteries: 96 lbs.
Component breakdown:
Front section w/o batteries: 27 lbs.
Rear section (w/o shroud, tray): 43 lbs.
Rear plastic shroud: 3 lbs.
Seat: 23 lbs.
Batteries (2 required): 25 lbs. each (12V, 32 AH)
Front-to-Rear Lockup Lock pin
Ground Clearance 4in.
Optional Accessories Cane/crutch holder, cup holder, front basket, front bumper,
headlight, oxygen holder, power seat assembly, rear basket, rear
bumper, rearview mirror, safety flag, taillight, walker holder
IV. SPECIFICATIONS
