Dynamo
27
IX.
DISASSEMBL
Y AND
ASSEMBL
Y
FIGURE 17. DISCONNECTING THE FRONT-TO-REAR
HARNESS
FIGURE 18. DISCONNECTING
THE BATTERY HARNESSES
FIGURE 20. REMOVE BALL
DETENT PINS WITH RING
FIGURE 21. SEPARATING THE
FRAME SECTIONS
FIGURE 19. BATTERY REMOVAL
26
28
