Jazzy Select Series www.pridemobility.com 19
III. YOUR POWER CHAIR
Figure 7. The Jazzy Select 6 Power Base
MAIN CIRCUIT BREAKER
XLR OFF-BOARD CHARGING HARNESS
Figure 6. The Jazzy Select Power Base
REAR SHROUD
SEAT POST
MAIN CIRCUIT BREAKER
FRONT COVER
CONTROLLER HARNESS
XLR OFF-BOARD CHARGING HARNESS
REAR SHROUD
CONTROLLER HARNESS
