Jazzy Select Series www.pridemobility.com 39
VII. CARE AND MAINTENANCE
Figure 24. Battery Installation (Seat Removed for Clarity)
CORRECT
CONNECTION
INCORRECT
CONNECTION
REAR BATTERY
FRONT
BATTERY
YELLOW
THUMBSCREWS
SIDE COVER
REAR
SHROUD
CONTROLLER
COVER SHROUD
