20 SC7132
EN
Figure 11. Battery Terminal Hardware
III. BATTERIES AND CHARGING
1
Figure 10. Battery Shroud Removal/Installation
IDENTIFICATION KEY
1. BATTERY SHROUD
IDENTIFICATION KEY
1. MAIN CIRCUIT BREAKER
2. BATTERY TERMINALS UNDER BOOTS
3. BATTERY TIE-DOWN STRAP
4. BATTERY HARNESS CONNECTORS
5. BATTERY COMMUNICATION HARNESS
6. *BATTERY DISCCONECT SWITCH
*IF EQUIPPED
Figure 12. Battery Removal/Installation Terminals and
Connections
5
3
1
4
4
2 2
6
