Pride Victory - Seat Positioning and Armrest Adjustment

28
Victory
FRONT-TO-BACK SEAT ADJUSTMENT
You can reposition the Victorys seat forward or rearward
to one of three settings to adjust the distance between the
seat and the tiller. See figure 13.
1. Remove the seat from your Victory. See VIII. Dis-
assembly and Assembly.
2. Remove the four bolts that fasten the seat platform to
the seat base.
3. Align the seat platform with the desired set of holes on
the seat base.
4. Reinstall the four bolts securely.
ARMREST WIDTH ADJUSTMENT
The armrest width of your Victory can be adjusted inward
or outward. See figure 14.
1. Loosen the thumbscrews at the back of the seat frame.
2. Slide the armrests in or out to the desired width.
3. Tighten the thumbscrews.
The armrests also pivot upward to make getting on and
off of your scooter easier.
SEAT LOCK LEVER
The seat lock lever locks the seat in one of five positions.
See figure 15.
1. Pull up on the seat lock lever to unlock the seat.
2. Rotate the seat to the desired position.
3. Release the seat lock lever to lock the seat securely in
place.
Figure 14. Armrest Width Adjustment
THUMBSCREWS
ARMRESTS
SEAT FRAME
VII. COMFORT ADJUSTMENTS
Figure 13. Front-To-Back Seat Adjustment
SEAT LOCK
LEVER
SEAT PLATFORM
SEAT BOLTS
PUSH
FORWARD
TO ROTATE
SEAT
Figure 15. Seat Lock Lever
SEAT BASE
