Primare SC15 - Connecting Direct Sources

SC15 Prisma System Control Center User Guide 11
OUT
ANALOG
IN
L
R
D2A1 D3 D4 D5 D6
DIGITAL IN
DIGITAL OUT
PC/MAC
SPS
USB
LAN
TRIG
OUT
IR-IN RS232IR-OUT
CON
SC15
WiSA Loudspeakers
Digital optical source
USB-A to USB-B cable
Digital optical cable
Coax cable
RCA cable
PC/Mac
Digital coax source
Analogue source
CONNECTING DIRECT SOURCES
These methods of playing music from the SC15 involve
connecting the source to the SC15 via a cable, and don’t
require Wi-Fi, Ethernet, or Bluetooth.
To play music from a source
Connect the source via a suitable cable:
Analogue Phono RCA cable
Digital optical source Digital optical cable
Digital source Digital coax cable
Select the source from the front panel, or using the
remote control.
If you have a phone or tablet on the same Wi-Fi network
as the SC15 you can also use the Prisma app to select
and control sources.
l
l
To use the SC15 as a PC/Mac sound output device
Connect the Mac or PC to the SC15 via a USB-A to
USB-B cable.
PC
Windows 7, 8, 8.1, or 10 (32/64-bit) is required. You
need to install the Primare xmos audio driver, available on
primare.net.
Macintosh
OSX 10.4 or later is recommended. No driver is required.
Connect the computer’s USB port to the USB B input on
the SC15 using a USB A to USB B cable.
The SC15 will then appear as a sound output device
called SC15 in the Sound control panel (PC) or Sound
system preferences panel (Macintosh).
Select the PC/MAC source on the SC15.
Select the SC15 as the sound output device in the
Mac Sound system preferences panel or the PC Sound
control panel.
