Primare SC15 - Back-Panel Connections

SC15 Prisma System Control Center User Guide8
The following diagram explains the function of each of the
connectors on the back panel:
BACK-PANEL CONNECTIONS
OUT
ANALOG
IN
L
R
D2A1 D3 D4 D5 D6
DIGITAL IN
DIGITAL OUT
PC/MAC
SPS
USB
LAN
TRIG
OUT
IR-IN RS232IR-OUT
CON
Analogue
output
Analogue
input
Coax
digital
input
Optical
digital/
analogue
input
Coax
digital
output
WiSA
transmitter
USB-B
input
Network
status
SPS
button
and status
Ethernet
and USB-A
input
Optical
digital inputs
Power and fuse
On/off
Trigger
IR
in/out
RS232
