6. Press in the hubshell seal, make sure that this is pressed in evenly and flat side of the seal is against the hubshell.
Once pressed in apply a thin layer of star ratchet grease around the seal.
If the hubshell seal is fitted either with the incorrect orientation, unevenly or not fully inserted this can cause
friction between the freehub and seal. This then will lead to poor rotation of the wheel and drag on the
freehub.
7. Apply a thin layer of ratchet grease over the surface of the star ratchet bushing highlighted in red. Then slide the
bushing over the axle until it seats against the drive side hubshell bearing.
17
