9. Apply Teflon anti-sieze grease the surface highlighted in red on the freehub body. Then using the bearing press with
the correct press for the freehub body bearing, insert the inner freehub bearing until it is fully seated within the
freehub.
The next steps go through the assembly and bearing replacement of the freehub. Ensure all parts are clean before re-fitment
and that the correct bearings are used that require replacing.
The following steps illustrate installation of bearings and hardware on a Prime XDR (SRAM) freehub. This is
purely for illustration purposes and the steps required to complete the process are the same across all types
of Prime freehubs. Different bearing specifications will be required depending on the freehub that is being
worked on so please use page 2 for guidance.
10. Using the circlip pliers re-fit the bearing retaining circlip into the freehub.
19
