INSLLION SET-UP FOR
SMAW (STICK) WELDING
INSLLION SET UP FOR SMAW (STICK) WELDING
DC+ Electrode connected to output receptacle.
DC- Electrode connected to
8
output receptacle.
Select the MMA function
with the MIG/MMA selector
Connect ground clamp
to the
8
receptacle.
Connect electrode lead
to the
receptacle.
Peld
OW
N
ER'SM
A
N
U
A
L
1
42
