8
When your Fridge/Freezer is first connected
to the AC or DC power input the appliance will
automatically switch on and the LCD control
panel will display the current cabinet temperature,
battery monitor and Eco setting as well as the
current input voltage.
• The Temperature Controller provides the ability
to set the desired temperature level and display
the current cabinet temperature. The electronic
controller has been programmed to maintain an
average of the set temperature.
• The compressor will start up when the internal
cabinet temperature increases 0.5 to 1.5 degrees
above the set temperature and will run until
the temperature is 0.5 to 1.5 degrees below
the set temperature.
Temperature Control
Battery Display
Voltage is measured at the input connection on the side of the appliance.
Battery Display 12V 24V
0 BARS 9.6V or less 21.3V or less
1 BAR 9.7V to 10.3V 21.4V to 22.4V
2 BARS 10.6V to 11.0V 22.7V to 23.5V
3 BARS 11.1V to 11.7V 23.6V to 24.6V
4 BARS 11.8V to 12.4V 23.7V to 25.7V
5 BARS 12.5V or above 25.8V or above
*Values are for reference only and may be subject to change depending on conditions and power supply.
