525928 Instruction AC-reactor FS16-55 RS27-35 P13/15
4.d) Instruction for RS27/35:
Place the AC-reactor on a suitable place in the
machine.
The most easy is to mount it in the corner of the
back panel, but it has the small disadvantage
that you always need to disconnect the wires if
you want to open the back panel.
Drill 4 holes (diam. 10mm) and fix the AC-
reactor with the included bolts and nuts.
Make sure that no burs from the drilling can
enter the frequency inverter or other
components.
