508913C PUBLICATION DATE 25 AUG 2006.DOC PROGRAMMING MANUAL 9
4. TABLE OF ERROR CODES, MESSAGES AND
TROUBLESHOOTING
4.1. TROUBLESHOOTING
Control system ensures complete control of the ironer. When a failure occurs, the machine will go
automatically to safety state.
Following table is a guide for solving of common problems.
4.2. SOLVING OF COMMON PROBLEMS
Problem Cause / state Problem solving
After switching ON the main
switch, the display doesn’t
light up.
• Failure in power supply
• Some of emergency stops is
pushed in (the buzzer
sounds in this case)
• The fuse in distributor or on
the control system is blown
• Check outer supply
• Deactivate (pull out) both
emergency stops
• Change the fuse; if it blows
again, then the failure is in
electrical installation
The machine doesn’t react
when pressing the buttons on
keyboard
• No button functions
• Safety bar or crank for
manual rotation is pushed in
(the button „Start“ doesn’t
work)
• Find out, if connector „S1“ of
keyboard is connected properly
• Loosen the bar and crank,
check, if micro switch of safety
bar or crank is not jammed
4.3. ERROR MESSAGES
It a failure occurs, the control system displays an error message and the siren will whistle discontinuously in
some cases.
4.4. HOW TO SOLVE ERROR MESSAGES
Find appropriate error message in manual.
Error message can be delete by pressing the button for automatic finishing of ironing.
4.5. TABLE OF ERROR MESSAGES
No. Error message Machine operation
001*
Temperature of ironing roller is higher than 200°C Machine operates normally, heating is OFF
002*
Temperature of ironing roller is higher than
80°C and roller does not rotate
Machine is stopped, it is possible to start it by
the button „Start“
003
Overloading of motor(s) of ventilator(s)
Machine changes to mode of automatic
finishing of ironing
004
Short circuit of temperature sensor
Machine goes on operating, heating is OFF.
Stopping the machine is possible only
by the main switch.
005*
Disconnection of temperature sensor
Machine goes on operating, heating is OFF.
Stopping the machine is possible only by the
main switch.
006
Failure of drive Machine is stopped
007
Underpressure switches are off
(gas heating only)
Machine is operating, heating is OFF
008
Failure of burner ignition (gas heating only) Machine is operating, heating is OFF
009
Crank for manual rotation of ironing cylinder is
pushed
Machine is stopped
010
Lifting up the trough (only machines with ironer
with front/rear delivery)
The machine operates normally, direction
of balancing is switched forward, speed
is reduced to minimum
011
Failure of underpressure switches Machine is operating, heating is OFF
012
Wrong function of safety bar
Machine control is blocked, machine can be
switched off only
013
Defective speed sensor (IF machines only) Machine is running without folding
255
See error No. 005 -
* = Message is accompanied with discontinuous sound of siren
