Primus Single Zone - Single Zone Operation; Power On;Off and Eco Function; Setting Temperature and Battery Monitor

9
Power – Off and On
1. Press and hold the power button for 2 to 3
seconds and the unit will power off
2. Press and hold the power button
for 2 to 3
seconds and the unit will power up and display
the current cabinet temperature
Eco Function – Setting
3. Press the mode button twice (2) and
the current function will flash
4. Adjust between Eco & Max by pressing the
up
button for Max or down button for Eco
5. The selected function will continue to flash
for 3 to 5 seconds
Cabinet Temperature – Setting
1. Press the mode button once (1) and
the temperature display will flash with the
current setting.
2. Adjust the temperature by pressing up
to increase and down
to decrease until
the selected temperature is reached
NOTE: Maximum temperature settings are from
-18°C to 10°C.
3. The selected temperature will flash on the
display for 3 to 5 seconds before displaying
the current cabinet temperature
Battery Monitor – Setting
1. Press the mode button three times (3)
and the battery monitor will flash with the
current setting
2. Adjust the setting by pressing the up
or down
button until the desired setting
is shown.
3. The selected setting will continue to flash
for 3 to 5 seconds
12V DC Input Cut out Cut in
H (High) 11.1V 12.4V
M (Medium) 10.1V 11.4V
L (Low) 9.6V 10.9V
24V DC Input Cut out Cut in
H (High) 24.3V 25.7V
M (Medium) 22.3V 23.7V
L (Low) 21.3V 22.7V
Single Zone Operation
1
Input Voltage Display
2
Up Button
3
Down Button
4
Power On/Off Button
5
Mode Button
6
Battery Monitor Display
7
Temperature Display
8
Mode Display
2
34
8
7
6
5
1
