Princess auto Drift hero - Tighten Jackshaft to Frame Mount Bolt; Secure Wires and Cables; Mount Throttle Cable; Ensure Free Movement of Cables

SECURE WIRES AND CABLES
9\ TIGHTEN THE JACKSHAFT TO FRAME
MOUNT BOLT (M8*20 BOLT)
TROUQE 13-18 ft.lbs
CAUTION: ALL THE PARTS ARE PUT IN THE
PAG WITH THE LABEL “CLUTCH ASSEMBLY”.
Jackshaft to Frame Mount Bolt
1\ MOUNT THE THROTTLE CABLE TO THE
ENGINE THROTTLE BRACKET AND CONECT
SWITCH OFF WIRE WITH THE ENGINE WIRE.
2\MAKE SURE THE ON/OFF SWITCH WIRE,
THROTTLE CABLE AND BRAKE CABLE ARE
NOT KINKED AND HAVE FREE MOVEMENT
WHEN THE HANDLE BAR ARE TRUNED FROM
LEFT TO RIGHT.
3\ SECURE WIRES AND CABLES TO FRAME
USING THE ZIP TIES PROVIDED.
Throttle Cable mount point
ON/OFF Switch Wire Conect Point
