Princess auto Drift hero - Engine Installation; Install Jackshaft Assembly to Engine; Tighten 4-M8*16 Bolts; Install Clutch to Engine Shaft

ENGINE INSTALLATION
1\ INSTALL THE JACKSHAFT ASSEMBLY TO
THE ENGINE OUTPUT SHAFT SIDE.
2\ TIGHTEN THE 4-M8*16 BOLTS:
TROUQE 13-18 ft.lbs
3\ INSTALL THE CLUTCH TO ENGINE SHAFT.
PUT THE PARTS LIKE THE FOLLOWING
ORDER:
CLUTCH BUSHING (20*25*5mm), CLUTCH ,
WASHER(8*25*3mm), M5/16-24*4/3 BOLT.
4\ TIGHTEN THE CLUTCH BOLT:
TROUQE 13-18 ft.lbs
5\ INSTALL THE CHIAN (JACKSAHFT
08MA-42) , TO CONECT THE CLUTCH AND
SECOND DRIVEN SPROKET.
Clutch Bushing
Clutch Assy
Washer and Spring washer
M5/16-24*4/3 Bolt
Engine Assembly
Drive Chian 08MA-42
4-M8*16 Bolt
Jackshft Assembly
