Instruction manual
5
INSTALLATION
Wall mounting
• Please note that the product must be installed at least 15 cm
from the floor and 50 cm from the ceiling.
• The heater must be mounted at 4 points, ensure there is a
300mm clearance on all sides of the heater.
• Measure the distance between the centre of each bracket both
horizontally and vertically to ensure drilling holes in the correct
place. Mark the positions of the 4 holes to be drilled on the wall
(1), use the supplied wall mount drawings for correct measures.
• Drill the holes in the wall (2), then insert the plastic expanded
plugs (3) and screw the 4 supplied screws into the plastic
expanded plugs (4).
• Attached the panel heater onto the screws and move the heater
to the left so that the screws drop into the securing slots (5).
Foot assembly
• If the heater is not mounted on the wall, the supplied feet must be
fitted to the unit.
• To fix the feet, remove the bottom screws from the heater
housing.
• Place the feet and secure them by putting the screws back into
the housing.
• Take care to ensure that the feet are located correctly on the
bottom end of the heater.
EN
