AM8604

2.1 Connect to AC Main

Connect your ampliﬁer to the AC main power source (power outlet) with the supplied AC power corset.

First, connect the IEC end of the corset to the IEC connector on the ampliﬁer; then, plug the other end of

the corset to the AC main.

WARNING: the third prong of this connector (ground) is an important safety feature. Do not attempt to disable

this ground connection by using an adapter or other methods. Ampliﬁer don’t create energy. The AC main

voltage and current must be suﬃcient to deliver the power you expect. You must operate your ampliﬁer from

an AC main power source with not more than a 10% variation above or a 15% variation below the ampliﬁer

speciﬁed line voltage and within the speciﬁed frequency requirements (indicated on the ampliﬁer back panel

label). If you are unsure of the output voltage of your AC main, please consult your electrician.

2.2 Startup Procedure

Use the following procedure when ﬁrst turning on your ampliﬁer:

• Turn down the level of your audio source.

• Turn down the level controls of the ampliﬁer.

• Turn on the Power switch. The Power indicator should glow.

• Turn up the level of your audio source to an optimum level.

• Turn up the Level controls on the ampliﬁer until the desired loudness or power level is achieved.

• Turn down the level of your audio source to its normal range.

- 2 - AC MAIN CONNECTION AND STARTUP

TECHNICAL DATA AM860

Output power RMS 120W

Constant impedance output 4 ohm - 16 ohm

Constant voltage output 70 / 100 V

Input Connectors Din balanced input for Mic1, 6.3mm jack for Mic 2 , 2 RCA for AUX / 2 RCA for CD

Output Connectors 4 - 16 ohm on terminal board out on terminal board

Frequency response 100 / 20000 Hz

Distortion (THD) < 2.5% (1 KHz)

Tone controls 150 Hz, 1KHz, 6kHz

Input volume controls Mic 1, Mic2, AUX/CD

Power Supply 230 V AC (+/- 5%)

Rack Units 2U (19” standard rack)

Dimensions (WxHxD) 90x270x260 mm

Weight 5 kg

1.2 Technical specications

Mixer - ampliﬁer.

• Designed for mixing and broadcasting announcements and music, diﬀusion in PA systems.

• Impedance constant outputs (4-16 ohm) and constant voltage outputs (70,100 V).

• Inputs: 2 Mic ,1 Aux / CD with selector.

• Priority function.

• 3 band EQ controls.

• Independent level controls for input signals.

• Rack tabs included (2U 19 ” standard rack).
