pro comp 57289 - Torque Specifications

57289
REVISED
2.1.06
12
TORQUE SPECIFICATIONS:
A-Arm Drop Bracket Bolts............... 100
ft./lbs.
Crossmember Bolts........................ 45
ft./lbs.
Eccentric Bolts.............................. 103
ft./lbs
Center Differential Bolts................ 70
ft./lbs.
Pass. Differential Brkt. Bolt........... 70
ft./lbs.
Drvr. Differential Brkt. Bolt........... 70
ft./lbs.
Tapered Spindle Sleeve Bolt........... 100
ft./lbs.
Brake Hose Brkt. to Spindle........... 120
ft./lbs.
Spindle to Upper Ball Joint............. 105
ft./lbs.
Tie Rod......................................... 67
ft./lbs.
U-Bolts......................................... 100 ft./lbs.
ILLUSTRATION 14
3 1/2” TAPERED
BLOCK 95-350
U-BOLTS
HIGH
NUT,
9/16”
FLAT
WASHER,
9/16”
F
R
O
N
T
O
F
V
E
H
I
C
L
E
