pro comp 57289 - Page 6

57289
REVISED
2.1.06
6
A-ARM
NOTE: BOLT
MUST BE IN-
STALLED AS
SHOWN.
A-ARM
DROP
BRACKET
EXISTING
HEX BOLT, 5/8”
X 4-1/2” LG.
LOCATING
SPACER
90-1301
LOCK NUT, 5/8”
EXISTING
EXISTING
ECCENTRIC
BOLT
ILLUSTRATION 3
A-ARM
DROP
BRACKET
REAR CROSSMEMBER
90-1290
NYLOC
NUT,
7/16”
FLAT
WASHER
, 7/16”
NYLOC
NUT, 7/16
HEX BOLT,
7/16” X 1”
LG.
FLAT
WASHER,
7/16”
HEX
BOLT,
7/16” x
1” LG.
FLAT
WASHER
, 7/16”
FLAT
WASHER
, 7/16”
ILLUSTRATION 4
