55728/K3099B/
K3101B
Created
7.25.15
6
the lower to 35 ft./lbs.
19. Reinstall the ABS and brake line brackets to
the vehicle using the previously removed OE
hardware.
20. On both sides of the vehicle, check the
routing of the brake lines and the ABS wire
harnesses. There must be no pinching,
rubbing, or stretching of either component.
Use zip ties to secure these items to the
steering components. At full droop, cycle the
steering from lock to lock while observing the
reaction of these components. Reposition
them if needed.
21. Reinstall the front wheels and lower the vehi-
cle to the ground. Torque the lug nuts ac-
cording to the wheel manufacturers recom-
mendations.
22. Reinstall the OE front track bar to the axle
mount using the previously removed OE
hardware. Torque the track bar mounting
bolt according to manufacturers specifica-
tions.
NOTES:
On completion of the installation, have
the suspension and headlights re-
aligned.
After 100 miles recheck for proper
torque on all newly installed hardware.
Recheck all hardware for tightness af-
ter off road use.
REAR INSTALLATION:
1. Block the front tires and raise the rear of the
vehicle. Support the frame with jack stands
forward of the rear springs.
2. Remove the rear wheels.
3. Unbolt the rear track bar from the rear axle
mount and secure up and out of the work
area. Save the hardware for reinstallation.
4. Remove the shocks on both sides of the vehi-
cle. It may be necessary that you slightly
raise the axle to unload the shocks for re-
moval.
5. Unbolt and remove the rear sway bar end
links from the vehicle. Save the hardware for
reuse.
6. Unbolt the rear brake line brackets from the
vehicle.
7. Lower the rear axle enough to remove the
coil springs from the rear spring pockets.
Save the factory isolators for re-use.
NOTE: Be sure to support the axle while
the springs and shocks are removed.
8. Install the driver side rear track bar relocation
bracket (91-5841) into the original track bar
mounting pocket using the supplied 9/16” X 3
1/4” bolt and supplied spacer (90-2650). See
ILLUSTRATION 2.
9. Insert the (2) 3/8” X 1” bolt into the track bar
bracket and secure it to the driver side rear axle
shock mount. See ILLUSTRATION 2.
