55728/K3099B/
K3101B
Created
7.25.15
8
20. Install the rear track bar to the relocation
bracket (91-5841) using the supplied adjust-
able cam bolt (90-3718) and hardware from
hardware pack (90-6529). Do not torque the
cam bolt at this time.
See ILLUSTRATION 2.
21. Position your vehicle on a smooth, flat, hard
surface (i.e. concrete or asphalt).
22. Rotate the track bar cam bolt until the wheels
are centered under the vehicle.
23. Torque track bar cam bolt to 103 ft./lbs.
24. Drive the vehicle forward and backward a
few feet to be sure that the axle is adjusted
properly and the vehicle is tracking in a
straight line.
IMPORTANT!: If the steering wheel is
not centered properly it will trigger the anti-lock
brake and traction control warning lights
.
NOTES:
On completion of the installation, have
the suspension and headlights re-
aligned.
After 100 miles recheck for proper
torque on all newly installed hardware.
Recheck all hardware for tightness af-
ter off road use.
