Because of it, the existing PLC connection cables cannot be used as they are. If you
use the existing connection cables, see [4.6 Cable Diagram at the time of
replacement].
2.7 Peripheral units and option units
2.7.1 Barcode reader connection
GP-4301TW is not equipped with a tool port. A barcode reader that used to be
connected to the tool port on GP-37W2 cannot be used. However, GP-4301TW
allows you to connect a barcode reader on its USB interface (Type A) or its serial
interface.
For the models GP-4301TW supports, see [OtasukePro!]
(http://www.pro-face.com/otasuke/qa/3000/0056_connect_e.html).
2.7.2 Isolation Unit
The isolation unit for GP-37W2 (CA2-ISOALL232-01 or CA2-ISOALL422-01)
cannot be used for GP-4301TW. Instead of it, please use the RS-232C isolation unit
for GP-4301TW (CA3-ISO232-01). In this case, select VCC” from [System
Settings] -> [Device/PLC] in the [Project] menu on GP-Pro EX.
2.8 Power Connector
The power connector on GP-4301TW is a spring lock type. If you replace GP-37W2
with GP-4301TW, change the power cable.
2.9 Power Consumption
The power consumption of GP-37W2 is different from that of GP-4301TW.
