Connectivity
22
RUN Mode Peripherals - COM1: RS-485 (isolation)
NOTE: For instructions on how to connect to other devices, always refer to the “GP-
Pro EX Device/PLC Connection Manual”.
GP unit
Host Controlle
r
PLC etc.
Serial Interface (COM1: RS-485 (isolation) mode)
PROFIBUS Cable
(Prepared by user)
RS-485 Cable
(Prepared by user)
MPI Cable
CA3-MPI-PG1-PFE
CA3-MPI-PGN-PFE
RS-485 (isolation) Port
RS-485 (isolation) Port
RS-485 (isolation) Port
