GP-4402WW/GP-4502WW Hardware Manual
29
Interface Specifications
Introduction
GP-4402WW/GP-4502WW is provided with serial, USB, and Ethernet interfaces.
Serial Interface RS-232C
This table describes the RS-232C serial interface:
Serial Interface RS-422/485
This table describes the RS-422/485 serial interface:
USB Interface (USB Peripherals)
This table describes the USB Type A interface:
USB Interface (Application Download)
This table describes the USB mini-B interface:
Interface Description
Serial interface D-Sub9
Asynchronous transmission RS-232C
Data length 7 bits or 8 bits
Stop bit 1 bit or 2 bits
Parity None, odd or even
Data transmission speed 2,400...115,200 bps
Interface Description
Serial interface D-Sub9
Asynchronous transmission RS-422/485
Data length 7 bits or 8 bits
Stop bit 1 bit or 2 bits
Parity None, odd or even
Data transmission speed 2,400...115,200 bps, 187,500 bps (MPI)
Interface Description
Host interface
Maximum current supplied 500 mA
Maximum transmission distance 3 m (9.84 ft) at 1.5/12/480 Mbps
Connector USB Type A 2.0
Interface Description
USB interface is used for application download
Maximum transmission distance 3 m (9.84 ft) at 12 Mbps, no long-term connections
Connector USB mini-B 2.0
Isolated None
