Status LEDs
The figure shows the LEDs of the Ethernet connector:
The table describes the Ethernet status LEDs operation:
Label Description LED
Color Status Description
IND1 Ethernet status Green Off No connection or subsequent
transmission failure.
On Data transmission is available.
IND2 Ethernet activity Green Off No data transmission.
On Data transmission is occurring.
