Installation and Wiring
44
6 When installing the panel in a slanted position, the panel face should not incline more than 30:
When installing the panel in a slanted position, and the panel face inclines more than 30, the
ambient temperature must not exceed 40 C (104 F). You may need to use forced air cooling
(fan, A/C) to ensure that the ambient operating temperature is 40 C or below.
7 For easier maintenance, operation and improved ventilation, install the panel at least 100 mm
(3.94 in) away from adjacent structures and other equipment:
Step Action
