8
3. With the help of another person, place some
sturdy packing materials under the front of the
Frame (1). Have the other person hold the
elliptical to prevent it from tipping.
If there are shipping supports attached to the
front of the Frame (1), remove the screws attach-
ing the shipping supports. Discard the screws
and the shipping supports.
Attach the Front Stabilizer (73) to the Frame (1)
with two M10 x 120mm Screws (84).
Then, remove the packing materials and lower
the elliptical.
3
4. With the help of a second person, raise the
Upright (2) to the vertical position.
See the inset drawing. Tighten the Upright
Knob (85).
4
1
84
73
2
85
To Next Page
