pro.point JPC60 - Parts Breakdown; Parts List - Base Plate

V1.2 JPC60 Plate Compactor 8570533
Visit www.princessauto.com for more information 19
PARTS BREAKDOWN
PARTS LIST - BASE PLATE
PART #
DESCRIPTION
QTY
PARTS
IDENTIFIER
A1
60 Base Plate WA (516x375 mm)
1
PA010-000
A2
Vibration Isolator Rubber(60)
4
PP130-001
A3
Engine Base Support Rubber
1
PA130-002
A4
Washer, M10 Ø30 (10.9T)
2
QWS-
SPM10H
A5
Nylon Nut, M10
4
QNT-NM10
A6
Washer, M10
4
QWS-PM10
A7
Spring Washer, M10
5
QWS-SM10
A8
Nut, M10
5
QNT-M10
