CARTON CONTENTS
Separate all parts from packing materials. Check each part with the
UNPACKING CARTON AND CHECKING CONTENTS
illustration on the next page and the “Table of Loose Parts” to make
certain all items are accounted for before discarding any packing
material.
If any part is missing or damaged, do not attempt to assemble the
table saw, plug in the power cord, or turn the switch ON until the
missing or damaged part is obtained and is installed correctl
For missing parts, please contact Customer service at 1-866-206-0888.
y.
PARTS LIST
ITEM DESCRIPTION QUANTITY
ASaw 1
A1 Saw table 1
B Longitudinal stop 1
C Angle stop 1
D Saw blade guard/Splitter 1
E Feet 4
F Strengthening bracket, top, short 2
G Strengthening bracket, top, long 2
H Strengthening bracket, short 2
I Strengthening bracket, long 2
J Rubber feet 4
K Hexagonal screws 20
L Washers 20
M Hexagonal nuts 20
N Pusher stick 1
O Mounting bracket with Philips screws 2
P Mounting bracket with Philips screws 1
Q Saw blade 1
R Table insert 1
T Hand wheel 1
T1 Crank handle 1
U ON/OFF switch 1
V Extraction adapter 1
W Hexagonal screws 4
X Open-ended spanner 2
Y Allen key 2
NOTE: To make assembly easier, keep box of contents
together. Apply a coat of automobile wax to the table.
Wipe all parts thoroughly with a clean dry cloth. This will
reduce friction when pushing the workpiece.
