Technical Data
‧Temperature range:
Operation:-10～50°C, max 80 % HR（Non-Condensed）
Storage:-10～50°C，max 80 % HR (Non-Condensed)
(removing batteries)
‧Sampling rate: ≥2 times/s。
‧Display: 3½ digits, 1999 counts, with analog bar display;
‧Sensor: silicon photoelectric diode
‧Measured spectral range: 320～730nm
‧Measurement ranges: 20, 200, 2000, 20000, 200000, Lux20, 200,
2000, 20000 FC
‧Operating environment: indoor use
‧Height: 2000m highest
‧Battery life: Approx. 200 hours
‧Power supply: 1×9 V，IEC 6LR61
‧Dimensions (H×W×D): 170 mm×85 mm×45 mm
‧Accuracy: ±3% (calibrated with incandescent lamps in
2854K) ±6% other visible light source
Tips: cosine angle is corrected in accordance with JIS C 1609:1993 and
CNS 5119 Grade A General Specification.
‧Luminous sensitivity characteristics:
